Solution for interactive slide screen

What is the interactive slide screen?

　　 Interactive slide screen is a common interactive display product in the multimedia industry of exhibition halls, also called slide TV, mobile slide screen, slide electronic window, slide perspective navigation machine, etc. The interactive slide screen refers to the quiet and stable sliding on the specific slide track through the motor control display screen, and the interactive control of the screen content is achieved by combining the high-definition LCD splicing curtain wall. When the slide screen slides to the designated position, the slide screen automatically plays pictures, text, video, audio and other related content, and carries out in-depth display and publicity of the display information with the background wall, The audience can also interact with the slide screen display content through touch, body feeling and other ways; The interactive slide screen fully reflects the practicality, interactivity and interest in one.

Operating principle of interactive slide screen:

The working principle of the interactive slide screen is that different touch points are set on the corresponding typeset pictures, and the sensing circuit device is installed on the sliding track in advance. When the visitors push the LCD TV to move to the preset touch sensing point, the sensing signal will be triggered, and the TV can automatically switch to the video related to the picture for playback.

Various case pictures are embedded on the exhibition wall similar to the coordinate axis, and a group of sliding mechanical structures are made to hang the LCD TV. Set different touch points on the corresponding pictures. Through the sensing circuit device installed on the track, the audience can push the LCD TV up, down, left and right. When moving to the corresponding touch sensing point, the screen coincides with the point. At this time, the sensing signal is triggered, and the screen will automatically play the video content of this part.

Composition structure of conventional software and hardware equipment of interactive slide screen:

The interactive slide screen system is mainly composed of hardware and software, and the detection of induced displacement can be accurate to mm. Through the specially designed mechanical slide rail control device, combined with the high-definition LCD splicing curtain wall, the interactive control of the screen content is achieved, and the relevant content will be displayed when sliding to different positions.

　　 Hardware : Touch screen, guide pulley, tank chain, rack, slide screen, slider, servo motor, motor controller, infrared sensor, light box, control host, etc

1. Touch screen: infrared touch screen host product customization, parameters can be recommended

2. Belt module: including sliding block, coupling, motor base, fixed base plate, radio and television switch, etc

3. Track: customized track, customized track length according to on-site requirements

4. Sliders: slider customization

5. Backplane bracket: customization of touch screen backplane bracket

6. Metal edging: process metal edging can be customized according to appearance requirements

7. Tank chain: The tank chain has a 3CM wide slot greater than 15CM deep to complete better sliding.

8. Servo motor

9. Control host

　　 Software : Control software, animation content

1. Control software: this set of control program is used to control the moving motor and the sliding of the interactive slide screen.

2. Animation content production: produced pictures, text, video, sound and other playing content.

What are the display types of the interactive slide screen?

At present, there are many types of slide rails on the market, but the structure is mainly wall mounted and floor mounted. The slide screen appears in the audience's view due to its special exhibition mode, which effectively attracts the attention of the visitors, deepens the impression of the display content in people's minds, and the display materials and content are also quite rich. You can freely add the content materials you want to display, which can bring the ultimate publicity and display effect. The interactive slide screen is often used for exhibition. What are its interactive display forms?

1. Multi linkage slide screen

Through the handle installed on the moving track, and multiple splicing screens as a whole display, slide the handle to different points, and different contents will be displayed on the splicing screen. (It is generally applicable to the timeline display, and used for the development process of enterprises and the party masses)

2. Manual slide screen

The light box is usually used as the background, and multiple sensing points and content materials are set on the track of the screen movement, which correspond to the content of the light box one by one. You can also manually push and pull the screen, and the points that pass will show different content.

3. Electric slide screen

The screen is driven forward by the electric device, and a virtual sensing point is set to enable the power device to start or stop. When the screen moves to the sensing point, the corresponding content will pop up. The software display content can also be adjusted as required, with additional functions such as automatic cruise and homing added.

4. Arc slide screen

The guide rail is required to move in an arc through the special environment of on-site installation. The sliding seat matched with the arc guide rail is a special sliding seat that can rotate along the arc guide rail to ensure the smooth operation of the roller without jamming.

5. Virtual explanation slide screen

By shooting a live interpretation film and placing it on the electric slide screen, the slide screen interacts with the physical exhibits according to the moving pace of the film interpreter. Create the ultimate virtual characters for the audience to show and explain.

Features of interactive slide screen system

1. The slide rail length can be customized according to the screen size. The guide rail has good contact, uniform pressure, flexible tracking, and the control and identification system is responsive;

2. The background map or background video can be customized, and the number and content of sensing points can be customized;

4. The position and size of the playback window can be customized;

5. It can play video, image and text information, and support round robin play;

6. Support the management of background data updates, which can be uploaded in real time and connected seamlessly.

Application advantages of interactive slide screen

1. This kind of interaction will attract more visitors to watch, and better achieve the role of publicity.

2. The amount of information carried by TV is huge, which can save more space than pictures and text, and can express more information that the organizers want to convey.

3. Once visitors approach the exhibition item, the large screen system will start immediately, which truly realizes automatic control. Multiple detection points can be controlled at the same time, making the entire exhibition hall more vivid and random, and truly realizing power saving, energy saving, low-carbon and environmental protection.

4. Even if the boring text image is displayed on the video, people will be interested in reading, and the burden of the commentator will be reduced. The empty explanation will become a three-dimensional animation form, which is easy for visitors to see at a glance, making the exhibition hall information release and product introduction more automatic.

5. It can bring very good interaction, so that customers are no longer constrained by the guidance staff's explanation. Customers are not constrained by the personal quality and level of guidance personnel. The presentation is more specific, comprehensive and shocking, which can give customers a very deep impression.

What are the application scenarios of the interactive slide screen:

museum

The exhibition directions of museums with different themes are also different, so the application of interactive slide screens in museums is also different. The interactive slide screen can be used to display details or restore exhibits. At the same time, it can also integrate creativity into the interactive slide screen to attract users' attention and show detailed information.

Exhibition hall

The interactive slide screen in the design of exhibition halls and pavilions is rich in content, multi-level and interactive, which can attract visitors to further understand the content related to the exhibition halls and pavilions, deepen users' impression of enterprises, improve users' stickiness to enterprises, and expand enterprise popularity.

exhibition

The interactive slide screen is used in the exhibition. Its LCD screen carries a huge amount of information, which can more express the information that the sponsor wants to transmit. Once visitors approach the exhibition, the large screen system will start immediately, which truly completes automatic control, and can control multiple detection points at the same time, making the entire exhibition hall more vivid and random, Truly achieve energy saving, low-carbon and environmental protection. The interactive slide screen can better attract visitors to watch and play a better role in publicity.

Product launch

The interactive slide screen is a new type of digital display, and its display means is a combination of dynamic and static mode composed of slide screen and background content. At the press conference, it was used to show the internal structure of the product and help the public better understand the product itself in more detail. The application of such interactive devices not only brought surprises, but also made the information display more colorful.

Urban Planning Museum

The interactive slide screen in the city planning museum, its automatic form track can better reflect the city's changing process with the rapid economic development, and its expectations for future urban planning. Through the rich content, diversified forms, and interesting interaction of dynamic and static combination of the interactive slide screen, visitors are guided to understand the relevant content of urban planning in detail, It better demonstrates the culture of the city, and also demonstrates the strength of the city, attracting investment and talent introduction.

The interactive slide screen is not only used in the above enterprise exhibition halls/pavilions, exhibitions, museums, memorial halls/pavilions, product launches, party building exhibition halls, conference halls, real estate exhibition halls, planning halls, etc. to display the content related to exhibition items, but also is now widely used in exhibitions, shopping malls, and stores. The large screen also has a large amount of information, which can save more space than pictures and text, and make the entire exhibition hall more upgraded.

Requirements and precautions for installation of interactive slide screen:

1. Before installation:

A Basic wall design: on the basis of ensuring that the wall corresponds to the necessary track screen, the basic design of the wall must conform to the layout of the entire exhibition hall.

B Design of reserved space: the design and construction parties must confirm the detailed drawings of the reserved space with the slide screen manufacturer, and must reserve the installation construction space according to the factory drawings.

2. Installing:

Generally speaking, the slides, motors, tank chains, power supplies and LCD screens need attention here.

Mute track: single slide and double slide; It may also be a straight slide or an arc slide.

Display screen: it can be advertising machine, touch all-in-one machine, splicing screen, transparent screen, LED large screen, LCD TV, etc.

Motor system: generally, it defaults to a relatively stable servo motor.

3. After installation:

Functions must be debugged again: this includes motor power system adjustment, track software control adjustment, track screen content display adjustment and stability test of each component.

This part is completed by on-site construction technicians.

matters needing attention:

1. Wiring: Pay attention to the wiring and wiring problems of the screen, sensor and Shennao host.

2. Handle with care: The large screen without handle should be handled with care to avoid scratching the screen.

3. Installation height: the installation height of the slide screen, which is convenient for the audience to operate and display.

4. Assembly operation: the edges and corners of equipment parts are sharp, and gloves/finger cots shall be worn as far as possible during assembly.

5. Edge decoration: the rail is installed with fixed edge decoration. When decorating, remember to protect the slide screen system.

6. Commissioning and maintenance: the commissioning personnel must be technically competent, have strong ability to solve problems on site, and be trained for customers, including the maintenance of timely response in the later stage.

How much is the production price of the interactive slide screen?

The following equipment costs are reference prices, slightly different according to market fluctuations, and are only for reference:

1. The sliding door motor is used to control the program cost between 5000-8000 sets

2. Photoelectric switch is used for 0-30cm diffuse reflection, and the cost is 150

3. Guide pulley concave guide rail convex pulley customized track, including power cord, costs 1000 sets

4. Control board 4 in 4 out * cost 200 pieces

5. 12V centralized power supply, 1 in 2 out 1 in 3 out, costs 110 pieces

6. Tank chain slotting more than 15cm deep costs 30 meters

7. The customized development cost of TV rack is 400 sets

8. The cost of customized development of control software is 3-10w/set

9. 55 inch all-in-one machine custom development cost is 11000 sets

Generally speaking, if the production content is in the form of graphics and text, the price is between 80000 and 200000; if the production content is in the form of animation, the price is between 150000 and 500000. The specific cost is also related to the specific needs of customers.

The interactive slide screen has various forms and can accept various types of customization, such as manual slide screen, automatic slide screen, somatosensory slide screen, transparent slide screen, arc slide screen, circular slide screen, floor slide screen, etc; According to the content, place, form, etc. of the exhibition, it is widely used in various fields, in which the amount of information can be displayed is rich, and various exhibition halls are very popular project products.
